The tri-axle aluminum asphalt tanker trailer features a 3D design, high-strength steel, and advanced welding. It offers large capacity, low transport cost, strong corrosion resistance, and long service life — perfect for asphalt transport in road construction and maintenance.
The tri-axle aluminum asphalt tanker trailer is specially designed for the efficient and safe long-distance transportation of hot asphalt and bitumen. It is manufactured using advanced equipment such as large specialized plate rolling machines and one-pass double-sided forming welding machines, ensuring stable quality. The trailer features a lightweight body, strong resistance to torsion, vibration, and bumps, and meets various road load-bearing requirements
Why Choose our Asphalt Tanker Trailer?
● Advanced Manufacturing Process:
Utilizes specialized welding equipment, sandblasting, rust removal, and baking paint techniques to ensure high-quality and stable production.
● High-Strength National Standard Steel:
Bitumen tanker trailer made from high-tensile, corrosion-resistant steel to ensure a solid and durable tank structure.
● Strict 100% Radiographic Inspection:
All key welds undergo X-ray testing in accordance with GB/T22456 standards to guarantee transportation safety.
● Optimized Welding Technology:
Features one-time welding with double-sided forming, enhancing sealing performance and extending tank service life.
● Large-Scale Production Base:
Covers a 130,000 m² manufacturing area, enabling mass production and comprehensive quality control throughout the process.
● Energy-Saving and Cost-Effective:
Robust structure with low maintenance requirements helps reduce operational and repair costs.
Product Applications
1.Asphalt & Bitumen Transport – For highway, city road, and airport construction.
2.Oil & Chemical Industry – Suitable for viscous and temperature-sensitive materials.
3.Infrastructure Development – Efficient asphalt supply for remote construction sites.
Key Features
High-Strength Aluminum Tank Body
Lightweight yet durable, effectively reduces fuel consumption while maintaining excellent structural integrity.Efficient Thermal Insulation System – Multi-layer insulation with high-performance materials keeps asphalt at the required temperature during long hauls.
Advanced Heating System
Equipped with a reliable thermal oil or burner heating system to ensure smooth unloading and prevent material solidification.Three-Axle Heavy-Duty Design – Ensures better load distribution, enhanced stability, and reduced tire wear.
Safety and Reliability
Integrated braking, anti-overflow valves, and emergency cut-off systems ensure safe operation at all times.Easy Operation and Maintenance – User-friendly layout for loading/unloading and cleaning, minimizing downtime and maintenance costs.
Technical Specifications
| Parameter | Dimensions | Overall Dimensions (mm) | L×W×H:11,500×2,480×3600 (the height will be confirmed by the specification of tractor) |
| Max. Payload (kg) | 30,000 | ||
| Fabric & Configuration | Main beam | Flange 10mm/10m,Web 5mm, | |
| Floor | bottom plate, 4mm side plate 3mm | ||
| Painting | Primer and topcoat | ||
| Tire | Type: 12R22.5, equip 13pcs per chassis | ||
| Rim | Type: 9.0*22.5, equip13pcs per chassis | ||
| Axle | Heavy Duty RHINOX13T*3sets | ||
| Locks | None | ||
| King pin | JOST 50# | ||
| Suspension | Three axle Mechanical suspension for heavy load | ||
| Leaf spring | 8pcs, 90*16mm, | ||
| Landing gear | 30 Ton | ||
| Brake system | Dual air brake system; No ABS | ||
| ABS | No | ||
| Electric system | 24V, LED lights. | ||
| Tool box | One | ||
| Spare tire carrier | Two | ||
| Oil Tank | None | ||
| Color | Choose | ||
