A tri-axle 40ft gooseneck chassis is a heavy-duty trailer designed for efficient container transport, featuring three axles for enhanced load distribution and compliance with weight regulations. Its gooseneck design improves maneuverability and stability, making it ideal for hauling 40ft shipping containers in ports, logistics, and intermodal operations.
Key Features
Enhanced Load Capacity
Maximum Payload: 40,000 lbs (18,144 kg)
GVWR: 60,000 lbs (27,216 kg)
Tri-Axle Configuration: 3 axles with 12,000 lbs capacity each
Container Compatibility: 20ft and 40ft standard containers
Superior Structural Design
Main Frame: High-tensile steel construction with 10" I-beam main rails
Gooseneck Design: 5th wheel coupling for superior maneuverability
King Pin: 2-5/16" standard with reinforced mounting
Deck Height: 48" from ground to deck surface
Advanced Suspension System
Air Ride Suspension: 8-bag air ride system for smooth transport
Axle Spacing: 60" between axles for optimal weight distribution
Braking System: ABS with 12.25" x 4" S-cam brakes
Applications
This versatile gooseneck chassis is ideal for:
Port and Dock Operations: Efficient container handling and transfer
Long-Distance Transportation: Cross-country freight operations with heavy loads
Construction Sites: Transporting equipment and materials
Logistics Centers: Intermodal container transport
Industrial Zones: Heavy cargo movement between facilities
Type | Tri axle 40ft GN chassis for container transport | ||
Parameter | Dimensions | Overall Dimensions (mm) | L×W×H:12,490×2,470×1530 |
Max. Payload (kg) | 40,000 | ||
Fabric & Configuration | Main beam | Flange 14mm/16m, | |
Floor | None | ||
Painting | Primer and topcoat | ||
Tire | Type: 12R22.5, equip 13pcs per chassis, ling long or Triangle | ||
Rim | Type: 9.0*22.5, equip13pcs per chassis | ||
Axle | Heavy Duty RHINOX13T*3sets | ||
Locks | 12pcs | ||
King pin | JOST 50# | ||
Suspension | Three axle Mechanical suspension for heavy load | ||
Leaf spring | 10pcs, 90*13mm, | ||
Landing gear | JOST | ||
Brake system | Dual air brake system; No ABS | ||
Electric system | 24V, LED lights. | ||
Tool box | One | ||
Spare tire carrier | Two | ||
Oil Tank | None | ||
Color | Choose | ||
Others | |||
